Post-Combustion NOx Control for Thermal Oxidation Systems
Equipment Profile
Thermal oxidizers (TOs) and afterburners are used to destroy volatile organic compounds (VOCs), hazardous air pollutants (HAPs), and combustible waste gas streams through high-temperature combustion. They are widely deployed in chemical processing, pharmaceutical manufacturing, oil and gas, and industrial coating and printing operations.
Types include direct-fired thermal oxidizers (DFTOs), regenerative thermal oxidizers (RTOs), catalytic oxidizers, and process gas enclosed combustors.
The NOx Challenge in Thermal Oxidation
Thermal oxidizers operate at high combustion temperatures — often 1,400°F to 1,800°F or higher — necessary to achieve high VOC and HAP destruction efficiency. These temperatures promote significant thermal NOx formation. In many applications, the NOx generated by the thermal oxidizer itself exceeds the NOx present in the incoming waste gas stream, creating a net NOx emission that must be controlled to meet permit requirements.
As air quality regulations have tightened, many thermal oxidizer installations that previously required only VOC/HAP control permits have been required to add post-combustion NOx controls — most commonly SCR systems installed in the thermal oxidizer exhaust stream.
EcoCAT System Design Approach
- Exhaust gas characterization for thermal oxidizer applications, including the effect of waste stream composition on NOx formation rates
- SCR reactor design for high-temperature TO exhaust, including catalyst selection for the specific temperature range and exhaust chemistry
- Heat recovery evaluation — waste heat from TO exhaust may support steam generation or combustion air preheating, affecting the temperature at the SCR catalyst
- AIG design for effective ammonia distribution in TO exhaust configurations, including non-standard duct geometries
- Reagent system design compatible with TO operating profiles — variable waste gas flow, composition, and thermal input
- Integration with TO combustion control systems for coordinated SCR operation
Afterburner Applications
EcoCAT designs and supplies afterburner systems for applications requiring auxiliary combustion to maintain destruction temperature or to combust low-BTU waste gas streams. Where afterburners are followed by SCR systems, EcoCAT engineers the complete post-combustion train as an integrated package — afterburner, heat recovery where applicable, AIG, SCR reactor, reagent system, and controls.
RTO-Specific Considerations
Regenerative thermal oxidizers present unique SCR integration challenges due to alternating flow direction through regenerative media beds and resulting exhaust temperature variability. EcoCAT evaluates these characteristics in detail to design SCR systems that maintain compliance across all phases of the RTO operating cycle.
